Key Features

Approximate Assembly Time: No assembly required

Batteries: 500mAh 2-cell Li-ion x 2

Motor Type: Brushed

Charger: USB Charger

Chassis Structure / Material: Steel Ladder Frame with Nylon Composite Crossmembers

Size/Scale: 1:18

Suspension: Solid Axle 4-Link

Water-Resistant: Yes

Shock Type: 55mm Oil filled type, Half-Alloy

Transmission: 3 speed electronic switch, Remote Shifting

Hub counterweight block: Yes, 4 weight blocks installed

Overview

Customers looking for a quality crawler in the 1:18 segment have struggled to find one with a reasonable price and truly RTR.  Until now the market has offered either a very poor quality toy-level one, or too expensive and complicated to start with. Not everyone wants to spend time to build, paint and trim their crawler, but they are looking for an easy to carry size vehicle which is already built and has the same chassis design and functionality as bigger vehicles. Additional features such as the realistic scale like body, alloy oil filled shock absorbers, lights, hub weight blocks, 3 speed electronic transmission and great crawling performance mean it can be used at home, at the office or outside and offer tons of enjoyment.



Unique Selling Points

1. Jam packed with high performance features normally only found on 1/10 or larger vehicles, for a sub $120 price point



2. Several functions appear for the first time in 1:18 scale - controllable lights, alloy oil damper, weights block, USB charger...



3. Realistic looking scale body style



Target Consumer

1. Beginners who want to start their crawler career with a quality vehicle, not a toy



2. Experienced crawler owners looking for a smaller vehicle that offers the features they are used to in larger crawlers, to use in a smaller space



Vehicle Specifications

Approximate Assembly Time: No assembly required - true RTR

Battery: 2 x 500mAh 2-cell Li-ion w/JST connector (included)

Body: Scale, silk printed

Motor Size: 180 51T reverse rotation

Motor Type: Brushed

Charger: USB Charger

Chassis Structure / Material: Steel Ladder Frame with Nylon Composite Crossmembers

Drive System: Shaft Driven 4WD

Completion Level: Ready-To-Run

Differential: Locked

Radio: 2.4GHz

Steering servo: Included

Size/Scale: 1:18

Speed Control: Included - fully proportional forward & reverse

Suspension: Solid Axle 4-Link

Vehicle Type: 4WD "Scale" Rock Crawler

Water-Resistant: Yes

Wheel Type: Black Molded

Shock Type: 55mm(2.16 in) Oil filled, partial alloy (4)

Brake Type: Electronic

Steering: 9g servo

Transmission: 3 speed electronic switch, Remote Shifting

Lights: Front & Rear LED (controllable)



Approach Angle: 55°

Departure Angle: 60°

Breakover Angle: 44°

Max climb angle: 50°

Max tilt angle: 45°

Axle articulation: 25°

Front Track: 119mm (4.68 in)

Rear Track: 119mm (4.68 in)



Ground clearance: 44mm capable: (1.73")

Ground clearance at standard ride: height 40mm: (1.57")

Axle ground clearance: 21mm: (0.83")

Height: 136mm (5.35 in)

Length: 263mm (10.30 in)

Width: 120mm (4.72 in)

Wheelbase: 150mm (5.90 in)



Front Shock Length: 55mm (2.16 inches)

Rear Shock Length: 55mm (2.16 inches)

Front Wheels: 25.4 x 15mm (1 x 0.6 inches)

Rear Wheels: 25.4 x 15mm (1 x 0.6 inches)

Front Tires: 54x 21mm (2.13 x  0.83 inches)

Rear Tires: 54x 21mm (2.13 x  0.83 inches)

Wheel Hex Size: 7mm

Battery Tray: 48 L x 30 W x 22mm H



Weight Blocks weight: 46g(1.62oz)

Running weight: 470g (1.03lbs)

Weight without battery: 442g (0.98lbs)

Body Weight with lights: 80g (2.82oz)



Pinion: 12T

Spur Gear: 24T

Transmission: 3 speed electronic switch, Remote Shifting

Drivetrain ratio: 35.5:1

Axle gearing: 2:1
